JAUL DRONE NUSATECH UAV FIXED WING FW15i

JAUL DRONE NUSATECH UAV FIXED WING FW15i

Hubungi Kami

Ready to Mapping, Consisting of : - Body EPO foam - Autopilot system - High resolution digital camera - Motor Kit - Body protector - Flight control - Long range telemetry system - Remote control - UHF module - Servo - GPS - FPV tx/rx - FPV camera - FPV monitor - FPV battery - Plane battery - Remote battery - Mission planning software - Laptop/netbook untuk ground station - Ground control monitoring software - Rugged carrier box   Software Processing Foto Agisoft Professional 3 hari Standard training : - Pengoperasian UAV - Lite Maintenance - Prinsip-prinsip dasar aerodinamika - Prinsip safety dalam operasional UAV - Prinsip radio system - Sharing knowledge dan pengalaman - ProsesingFotogrammetri

View detail

JUAL AUTOMATIC LEVEL TOPCON ATB-4

JUAL AUTOMATIC LEVEL TOPCON ATB-4

Hubungi Kami

Panjang	215mm (8.46 in.)
Gambar	Tegak
Pembesaran	24X
Obyek Lensa	32mm (1.26 in.)
Daya Pemecah	4"
Sudut Pandang	1°25’ (at 100m/328ft.)
Min. Fokus dari Ujung Teleskop	0.2m (7.9 in.)
Min. Fokus dari Pusat Instrumen	0.3m (1 ft.)
Konstan Stadia	0
Rasio Stadia	100
Fokus Knob	1-speed
Panduan Penampakan	Pemitar
Tanpa Micrometer	2.0mm (0.08 in.)
Dengan Micrometer	0.5mm (0.02 in.)
Tipe	Pendulum kompensator dengan sistem redaman magnetik

Pengaturan Akurasi	0.5in
Rentang Waktu	±15 ft.
Kepekaan	10 ft./2mm
Diameter	103mm (4.1 in.)
Divisi Minimum	1°/1gon
Tingkat Tahan Air	IPX6
Suhu Temperatur	-4°F to +122°F (-20ºC to +50ºC
Dimensi	130 x 215 x 135 mm
Berat	3.7 lbs. (1.7kg)

View detail

JUAL AUTOMATIC LEVEL TOPCON ORION 2LS

JUAL AUTOMATIC LEVEL TOPCON ORION 2LS

Hubungi Kami

(distance) ±10mm @ 10m
Working range (Tape staff) 0.9 to 30m (2.9 to 98ft)
Working Range (Aluminum Staff) 2.0 to 50m (6.5 to 164ft)
Measuring time <2sec
Magnification 20X
Self-compensation range ±12°
Telescope
Length 206mm
Magnification 20X
Objective aperture 30mm (1.18in.)
Resolving power 4.5″
Field of view 1°20′
Minimum focus 0.9m (2.9ft)
Image Erect
Stadia ratio 1:100
Stadia constant 100

Type	Pendulum compensator with magnetic damping system
Working range	±12′

Height Measurement
Accuracy
Electronic reading	±2.0mm at 30m
Optical reading	±2.0mm at 30m
Measuring range
Tape staff BCX	0.9 to 30m (2.9 to 98ft)
Aluminum staff BAS	2.0 to 50m (6.5 to 164ft)
Measuring time	<2sec
Least count	0.001m, 0.01ft
Minimum light for measurement	20lx. @ staff surface

View detail

JUAL THEODOLITE TOPCON DT 200

JUAL THEODOLITE TOPCON DT 200

Hubungi Kami

DT-200 Series mengintegrasikan sama berkualitas tinggi maju mutlak membaca lingkaran teknologi yang ditemukan dalam performa tinggi Topcon produk total station untuk perhitungan lapangan lebih akurat. Tersedia dalam 5 “, 7″, atau 9 “akurasi sudut, ada DT-200 teodolit sempurna untuk pekerjaan apa pun. Kompak dan ringan untuk portabilitas mudah, DT-200 Series memberikan pengukuran yang tepat dalam fungsional, paket bebas repot. Sebuah sinar laser dipancarkan langsung dari aperture, tetapi tidak menghambat melihat dan tidak terlihat ketika pengamatan melalui lensa, namun dapat terlihat jelas di bawah sinar matahari hingga 50 m pergi sehingga dapat dengan mudah dan akurat menempatkan baut jangkar, menetapkan sudut dan menggunakan balok untuk memverifikasi meteran Anda benar sejajar untuk pengukuran berikutnya. Direkomendasikan untuk: Situs set-out Cocok untuk: persiapan lokasi, perkerasan, drainase Baterai yang tahan lama, dengan 140 jam operasi dari 4 “AA” baterai (w / out laser) Koreksi sudut vertikal memberikan ± 3 menit akurasi Tahan air dan tahan debu perumahan – IP66

Gas bermuatan teleskop

PECIFICATIONS :
Length	149 mm
Objective lens	40 mm
Magnification	26 x power
Field of view	1°30′
Resolving power	2.5 power
Minimum focus	90 cm
Stadia ratio	100
Stadia constant	0
Sighting collimator	Double

View detail

JUAL TOTAL STATION TOPCON CYGNUS 2LS

JUAL TOTAL STATION TOPCON CYGNUS 2LS

Hubungi kami

Reflectorless Total Station

The Cygnus (designed by Topcon) provides superior performance at an unbeatable price for survey and construction applications. It's built tough to survive in extreme conditions, yet easy to set up and put to work quickly. Cygnus features 200m reflectorless operation and up to 2,000m using a single prism. There's even a built-in laser pointer to aid in layout work. With a 24-key alphanumeric interface, 24,000 point capable memory, and up to three days of operation off of a single charge, Cygnus is the perfect solution for medium duty survey and construction layout.

Package includes:
*Topcon Cygnus KS-102 Reflectorless Total Station (2-Second)
*Tool kit
*Plastic carrying case
*Plastic rain cover
*Silicon cloth
*Li-Ion battery
*Battery charger
*User manual
*1-year manufacturer's warranty

Key Cygnus features include:

* 2" angle accuracy
* 1"/5" angle resolution
* 2000m single prism/200m reflectorless EDM range
* 1.1 sec. measurement time
* IP54 waterproof rating
* Approx. 23 hours of battery operation (@ 20ºC)
* Design and Quality by TOPCON, Japan

View detail

JUAL TOTAL STATION TOPCON GTS 255

JUAL TOTAL STATION TOPCON GTS 255

Hubungi Kami

Telescope
Length 150 Millimeters
Objective Lens Diameter 45mm ( EDM: 50mm)
Magnification 30x
Image Erect
Field of View 1° 30
Resolve Power 3 "
Min. Focus Distance 1.3 meters
Measurement Range
1 Prism 6560 ft, 2000 meters
3 Prism 8856 ft, 2700 meters
Measuring Accuracy
Prism Mode ± ( 2mm + 2ppm x D) m.s.e. fine, N/ A
Measurement Time 1mm: 1.2sec. ( Initial 4sec.) fine, 0.2sec. ( Initial 3sec.) coarse, N/ A
Angle Measurement
Method Absolute Reading
Detection 2 horizontal, 1 vertical
Minimum reading 5” / 1” , 1/ 5 mgon
Tilt Correction
Type Automatic Vertical and Horizontal compensator
Method Liquid surface reflective profile sensor reading type
Compensating Range ± 3'
Correction Unit 1 arc sec, N/ A
Computer Unit
Display 2 screen, dot matrix graphic LCD display
Power
Approximate battery life 9 hours including distance measurement , 40 Angle measurement only

View detail

JUAL TOTAL STATION TOPCON ES 105

JUAL TOTAL STATION TOPCON ES 105

Hubungi Kami

·         Reflectorless    ·         1,640' range    ·         Transfer data via Bluetooth, USB, or serial port    ·         Rechargeable battery good for 36 hours    ·         IP-66 rating against water and dust    ·         Black and white LCD display    ·         Keyboard for data entry    ·         TSshield system    ·         Laser pointer and plummet    ·         LongLink for system updates    ·         Weight 12.3 lbs (5.6 kg)    ·         Dimensions 7.5 in x 7.5 in x 13.7 in (19.1 cm x 19 cm x 34.8 cm)    ·         Protection Class IP66 (dust proof and powerful water jets and heavy seas resistant       Internal Memory 10,000 points ·         Guide Light Green and red LED; Operating time: 1.3 to 150 m (4.3 to 490 ft) ·         Minimum Reading 0.5-second/1-second ·         Accuracy 5-second ·         Unit of Measure (distance display)m/ft ·         EDM Accuracy (Precision)±(2mm + 2ppm x D) for prism; ±(3mm + 2ppm x D) for no prism ·         Minimum Reading 500 m (1,640 ft) ·         Tilt Sensor/Compensator Range ± 6, Type Liquid, Method Electronic Automatic ·         Battery/Power Power Source Rechargeable Li-ion battery, Battery Life 36 hours, Battery Life Alert ·         Telescope Length of Tube 6.7 in (17.1 cm), Diameter of Objective Lens (Aperture) 1.9 in (48mm) EDM, Magnification 30x, Field of View 1 degree 30 arcmin, Resolving Power 2.5 arcsec, Minimum Focus Distance 1.3 m (4.3 ft), Reticle Illumination 5 brightness levels, Reflectorless ·         Display and Keypad Type Black and white LCD, Sides Dual, Keys Alphanumeric, Backlight ·         Temperature Operating -4Fº~140ºF (-20ºC~60ºC) ·         Applications : Surveying and Construction, Mapping and GIS (geographic information systems), Utilities, Environment Studies, Geomarking, Archaeology, Accident Reconstruction. ·         Measurement Range (under fair weather conditions : Single Prism 4,000 m (13,123 ft), Triple Prism 5,000 m (16,404 ft, Reflector Sheet 500 m (1,640 ft). ·         Interface Bluetooth Class 1 LongLink technology, USB Type A and mini B, Pin Port RS-232C. Functions : Coordinate Measurement Point, Angle and Distance Stake Out, Stake Out Line, Offsets, Missing Line, Remote Elevation, Resection, Area Calculation.

View detail
